Lichuan Closed Loop Integrated Stepper Motors Driver 1.0N.m 2Phase Nema23 36V 4.0A 1000PPR

Lichuan L Shaped Closed Loop Integrated Stepper Motors Driver

Open Loop & Closed Loop Integrated Motion Control Solution

Product Introduction

Lichuan L Shaped Closed Loop Integrated Stepper Motors Driver is a compact, high-performance motion control solution that integrates stepper motor, driver and encoder into one unit.
Available in both open loop and closed loop configurations, this series provides flexible torque options from 0.4N·m up to 12N·m, making it ideal for a wide range of industrial automation applications.

Product Overview

The L Shaped Closed Loop Integrated Stepper Motors Driver adopts a space-saving right-angle (L-shaped) structure, significantly reducing installation depth while maintaining excellent heat dissipation and mechanical stability.
With multiple voltage, current and frame size options, it is designed for OEM manufacturers and system integrators seeking reliable, cost-effective motion solutions.

Key Product Information

• Product Type: L Shaped Integrated Stepper Motor with Driver

• Control Mode: Open Loop / Closed Loop Optional

• Phase: 2-Phase Stepper Motor

• Encoder: 1000PPR (Closed Loop Version)

• Keyword Focus: Closed Loop Integrated Stepper Motors Driver

Product Description

The Lichuan L Shaped Closed Loop Integrated Stepper Motors Driver uses encoder feedback to monitor motor position and speed in real time.
When deviation occurs, the driver automatically compensates current and torque output, effectively eliminating step loss and improving positioning accuracy.

Compared with traditional separate motor and driver solutions, this integrated design simplifies wiring, reduces installation time, and enhances overall system reliability.

Specifications Overview

• Rated Torque Range: 0.4N·m – 12N·m

• Frame Sizes: Nema17 / Nema23 / Nema24 / Nema34

• Supply Voltage: DC 24V / 36V / 48V

• Rated Current: 2.5A / 4.0A / 6.0A

• Encoder Resolution: 1000PPR

• Control Signal: Pulse & Direction

• Structure: L Shaped Integrated Design

Product Selling Points

• True closed loop control, zero step loss

• Compact L-shaped structure for space-limited equipment

• Wide torque coverage from light to heavy load applications

• Lower cost alternative to servo systems

• Stable and reliable Closed Loop Integrated Stepper Motors Driver

Product Features

• Motor + Driver + Encoder integrated

• Open loop and closed loop versions available

• Dynamic current control technology

• High rigidity output shaft

• Industrial-grade Closed Loop Integrated Stepper Motors Driver design

Product Technology

The Lichuan Closed Loop Integrated Stepper Motors Driver adopts advanced digital signal processing and closed loop vector control algorithms.
Encoder feedback continuously compares actual motor position with command signals, enabling automatic correction for smooth and precise motion.

Working Principle

1. Controller sends pulse command

2. Motor executes motion

3. Encoder feeds back real-time position

4. Driver calculates deviation

5. Current and torque are automatically adjusted

This closed loop control principle ensures accurate positioning even under load changes.

Application Fields

• CNC machines and engraving equipment

• Laser cutting and marking systems

• Packaging and labeling machines

• Industrial robots and linear actuators

• Automated production lines

All above systems benefit from Closed Loop Integrated Stepper Motors Driver solutions.

Product Applications

• Precision positioning systems

• Medium and heavy load transmission

• Long-time continuous operation

• Servo motor replacement in cost-sensitive projects

Technical Parameter Table

Product Advantages

• Simplified system architecture

• Reduced wiring and maintenance

• High positioning accuracy

• Strong anti-interference capability

• Mature and proven Closed Loop Integrated Stepper Motors Driver platform

Product Services

• Professional motor selection support

• OEM / ODM customization

• Wiring and parameter guidance

• Batch supply guarantee

• Long-term technical support

FAQ

Q1: What is the difference between open loop and closed loop versions?
A: Closed loop versions use encoder feedback to eliminate step loss, while open loop versions focus on cost efficiency.

Q2: Can this replace servo motors?
A: Yes, in many medium-power applications, the Closed Loop Integrated Stepper Motors Driver offers similar performance at lower cost.

Q3: Do you support customization?
A: Yes, voltage, shaft, encoder and cable length can be customized.

Manufacturing Process

• Precision motor winding

• CNC machining of motor housing

• Automated assembly line

• Encoder calibration

• 100% performance testing

Each Closed Loop Integrated Stepper Motors Driver undergoes strict quality control before delivery.

Operation Guide

1. Connect power supply correctly

2. Wire control signals

3. Set current and micro-step parameters

4. Perform no-load testing

5. Apply load and fine tune system

Precautions

• Do not hot-plug motor cables

• Ensure proper heat dissipation

• Avoid overload operation

• Use stable power supply

Correct usage ensures long service life of the Closed Loop Integrated Stepper Motors Driver.

Company Profile

Lichuan is a professional manufacturer specializing in motion control products, with extensive experience in integrated stepper motor and closed loop drive systems.
Our products are widely used in industrial automation, CNC machinery and intelligent equipment worldwide.

Certificates

• CE Certification

• RoHS Compliance

• ISO9001 Quality Management

• Multiple technical patents

Quality Assurance

• 100% factory inspection

• Strict raw material control

• Traceable production batches

• Stable long-term supply capability

Customer Service

• Fast technical response

• English documentation support

• Remote debugging assistance

• After-sales service system

We are committed to delivering reliable Closed Loop Integrated Stepper Motors Driver solutions for global customers.
