Lichuan Closed Loop Integrated Stepper Motors Driver 12N.m 2Phase Nema34 48V 6.0A 1000PPR

Product Introduction

Closed Loop Integrated Stepper Motors Driver by Lichuan is an L-shaped integrated motion control solution combining stepper motor, driver, and encoder in one compact unit. Covering torque ranges from 0.4N.m to 12N.m, this Closed Loop Integrated Stepper Motors Driver supports NEMA17, NEMA23, NEMA24, and NEMA34, making it suitable for light-duty to heavy-duty industrial automation applications.

Product Information

The Lichuan Closed Loop Integrated Stepper Motors Driver is available in both closed-loop and open-loop versions. It supports 24V / 36V / 48V DC, current options 2.5A / 4.0A / 6.0A, and integrates a 1000PPR incremental encoder for closed-loop models. The L-shaped structure allows flexible installation and compact cabinet design.

Product Description

This Closed Loop Integrated Stepper Motors Driver series integrates motor, drive, and control electronics into a single housing, reducing wiring complexity and improving system reliability. With torque options from 0.4N.m, 0.8N.m, 1.0N.m, 2.0N.m, 3.0N.m, 3.5N.m, 4.0N.m, 4.5N.m, 8.5N.m, 10N.m to 12N.m, it covers a wide range of industrial scenarios.

Product Parameter Table

Basic Information

• Brand: Lichuan

• Product Name: Closed Loop Integrated Stepper Motors Driver

• Structure: L-Shaped Integrated Design

• Phase: 2 Phase

• Control Mode: Closed Loop / Open Loop Optional

• Encoder: 1000PPR (Closed Loop)

• Frame Sizes: NEMA17 / NEMA23 / NEMA24 / NEMA34

Specifications

• Rated Voltage: DC 24V / 36V / 48V

• Rated Current: 2.5A / 4.0A / 6.0A

• Torque Range: 0.4N.m – 12N.m

• Encoder Resolution: 1000PPR

• Cooling Method: Natural Cooling

• Installation: Standard NEMA Mounting

The Closed Loop Integrated Stepper Motors Driver supports OEM parameter configuration.

Product Selling Points

• Wide torque coverage from 0.4N.m to 12N.m

• One series supports NEMA17 to NEMA34

• Closed-loop feedback eliminates step loss

• Open-loop option for cost-sensitive projects

• Compact L-shaped Closed Loop Integrated Stepper Motors Driver design

Product Features

• Motor + Driver + Encoder integrated

• Closed loop and open loop selectable

• Anti-resonance control algorithm

• Over-voltage, over-current, over-temperature protection

• Easy upgrade from traditional stepper systems

All features are optimized for the Closed Loop Integrated Stepper Motors Driver platform.

Product Technology

The Closed Loop Integrated Stepper Motors Driver adopts DSP-based digital control with encoder feedback. By dynamically adjusting current and torque, the system maintains precise positioning under varying load conditions.

Working Principle

The Closed Loop Integrated Stepper Motors Driver compares command signals with real-time encoder feedback (1000PPR). Any deviation is corrected instantly through current regulation, ensuring stable motion without step loss.

Application Fields

• CNC engraving and cutting machines

• Packaging and labeling equipment

• Industrial automation systems

• Robotics and intelligent equipment

• Medical and laboratory automation

• Textile, printing, and woodworking machinery

Product Usage

The Closed Loop Integrated Stepper Motors Driver is widely used for linear actuators, ball screw modules, conveyors, rotary tables, and positioning platforms requiring reliable motion control.

Product Advantages

• One platform covers multiple torque levels

• Reduced wiring and cabinet space

• Higher reliability than open-loop stepper motors

• Lower cost compared with servo systems

• Flexible selection for different applications

The Closed Loop Integrated Stepper Motors Driver reduces total system cost.

Product Services

• OEM / ODM customization

• Parameter tuning support

• Wiring diagrams and manuals

• Global shipping and logistics

Production Process

• Motor winding and assembly

• Encoder installation and calibration

• Driver PCB assembly

• Integrated system aging test

• Final quality inspection

Operation Method

1. Connect DC power supply

2. Wire control signals

3. Set parameters according to motor size

4. Perform no-load test

5. Install into equipment

Precautions

• Use correct voltage and current rating

• Ensure proper heat dissipation

• Avoid incorrect wiring of encoder

• Follow installation manual strictly

Company Introduction

Lichuan specializes in integrated motion control solutions, including Closed Loop Integrated Stepper Motors Driver, integrated servo motors, and automation products. Our solutions are exported worldwide for industrial applications.

Product Certificates

• CE Certification

• RoHS Compliance

• ISO9001 Quality System

Quality Assurance

Every Closed Loop Integrated Stepper Motors Driver is strictly tested for performance, reliability, and safety before delivery.

Customer Service Information

• Pre-sales technical consultation

• After-sales technical support

• 24-hour response service

• Long-term project cooperation

FAQ

Q1: What is the difference between closed loop and open loop models?
A: Closed-loop Closed Loop Integrated Stepper Motors Driver uses encoder feedback to prevent step loss, while open-loop is more cost-effective.

Q2: Can one driver cover multiple NEMA sizes?
A: Different frame sizes use different motor models, but all belong to the same product series.
