Place of Origin:
China
Brand Name:
Lichuan
Certification:
ISO9001 CE RoHS EPR EMC LVD IEC/EN60034-1 IEC62321
Model Number:
LCMT-38MAC23NB-130M15025B+LCDA-3818C23-M2532P
| NO. | Item No. | Description | QTY |
| 1 | LCDA-3818C23-M2532P | Lichuan 3.8KW Servo Motor Driver | 1PC |
| 2 | LCMT-26MCC23NB-130M10025B | 130 Motor, 15N.m, 3.8KW, 2500rpm, 3phase 220v | 1PC |
| 3 | Lichuan Power cable | 3M servo power cable (Longer cable available) | 1PC |
| 4 | Lichuan Encoder cable | 3M servo encoder cable (Longer cable available) | 1PC |
| 5 | Lichuan Instruction book | Instruction book | 1PC |
Product Name: 130 series AC servo motor
Lichuan 130 series AC servo motor contains 1KW, 1.3KW, 1.5KW, 2KW, 2.3KW, 2.6KW, 3.8KW power specifications, the motor adopts Japan Tamagawa 2500 cable encoder, advanced magnetic circuit design and high temperature permanent magnet material , Servo motor running smoothly, the noise is very small, suitable for a variety of industrial automation equipment, high precision control applications.
| Motor Model |
LCMT-10L02-130M 04025 |
LCMT-13L02-130M 05025 |
LCMT-15L02-130M 06025 |
LCMT-20L02-130M 07725 |
LCMT-10L02-130M 10010 |
LCMT-15M02-130M 10015 |
LCMT-26M02-130M 10025 |
LCMT-23ML02-130M 15015 |
LCMT-38M02-130M 15025 |
| Rated Power (KW) | 1.0 | 1.3 | 1.5 | 2.0 | 1.0 | 1.5 | 2.6 | 2.3 | 3.8 |
| Rated Voltage (V) | 220 | 220 | 220 | 220 | 220 | 220 | 220 | 220 | 220 |
| Rated Current (A) | 4.0 | 5.0 | 6.0 | 7.5 | 4.5 | 6.0 | 10 | 9.5 | 13.5 |
| Rated Speed(rpm) | 2500 | 2500 | 2500 | 2500 | 1000 | 1500 | 2500 | 1500 | 2500 |
| Peak Torque (N.M) | 4.0 | 5.0 | 6.0 | 7.7 | 10 | 10 | 10 | 15 | 15 |
| Holding Torque (N.M) | 12 | 16 | 18 | 22 | 20 | 25 | 25 | 30 | 30 |
| Voltage constant (V/1000r/min) | 72 | 68 | 65 | 68 | 140 | 103 | 70 | 114 | 67 |
| Torque coefficient(N.M/A) | 1.0 | 1.0 | 1.0 | 1.03 | 2.2 | 1.67 | 1.0 | 1.58 | 1.11 |
| Rotor inertia(kg.m2) | 0.85×10-3 | 1.06×10-3 | 1.26×10-3 | 1.53×10-3 | 1.94×10-3 | 1.94×10-3 | 1.94×10-3 | 2.77×10-3 | 2.77×10-3 |
| Phase Resistance(Ω) | 2.76 | 1.84 | 1.21 | 1.01 | 2.7 | 1.29 | 0.73 | 1.1 | 0.49 |
| Phase Inductance(mH) | 6.42 | 4.9 | 3.87 | 2.94 | 8.8 | 5.07 | 2.45 | 4.45 | 1.68 |
| Mechanical time constant (Ms) | 2.32 | 2.66 | 3.26 | 3.80 | 3.26 | 3.93 | 3.36 | 4.05 | 3.43 |
| Weight (KG) | 7.7 | 8.2 | 8.9 | 10 | 11.5 | 11.5 | 11.5 | 14.4 | 14.4 |
| Encoder line Number (PPR) | 2500 | ||||||||
| Insulation/Safety Classs | Class B ( (130℃) IP66 | ||||||||
| Operating Environment | Temperature:-20℃~+50℃ Humidity:Below <90%(No dewing) | ||||||||
| Motor winding | Winding lead wire | U | V | W | PE | ||||
| Plug serial number | 2 | 3 | 4 | 1 | |||||
Suitable for a variety of sports control automation equipment and equipment, such as: mechanical arm, cutting machine, fuel injection machine, ultrasonic equipment, feeding equipment, printing equipment, medical equipment, packaging equipment, lithium battery equipment, CNC lathes, spraying equipment, Equipment and so on.
