Lichuan Closed Loop Integrated Stepper Motors Driver 0.4N.m 2Phase Nema17 24V 2.5A 1000PPR

Lichuan Closed Loop Integrated Stepper Motors Driver 0.4N.m 2Phase Nema17 24V 2.5A 1000PPR

Lichuan L Shaped Closed Loop & Open Loop Integrated Stepper Motors Driver

Compact L-Type High-Torque Motion Control Solution

Product Introduction

The Lichuan L Shaped Closed Loop Integrated Stepper Motors Driver is a compact, high-performance motion control solution that integrates a stepper motor, digital driver, and optional encoder into a single L-shaped structure.
It supports both closed loop and open loop control modes, providing flexible configuration for different automation and CNC applications.

With multiple torque options from 0.4N.m to 12N.m, various frame sizes from NEMA17 to NEMA34, and voltage support of 24V / 36V / 48V, this Closed Loop Integrated Stepper Motors Driver series is designed to meet diverse industrial requirements.

Product Information

The Lichuan L Shaped Closed Loop Integrated Stepper Motors Driver adopts a modular integrated design, reducing installation space while improving wiring efficiency and system stability.

Available in both open loop integrated stepper motors driver and closed loop integrated stepper motors driver with 1000PPR encoder, this series offers excellent positioning accuracy, torque stability, and anti-resonance performance.

Product Description

This Closed Loop Integrated Stepper Motors Driver combines motor, driver, and feedback system into a compact L-shaped housing, making it ideal for space-limited equipment designs.

The closed-loop version uses real-time encoder feedback to eliminate step loss, while the open-loop version provides a cost-effective solution for standard positioning tasks.

Basic Information

• Product Name: Lichuan L Shaped Closed Loop Integrated Stepper Motors Driver

• Control Mode: Closed Loop / Open Loop Optional

• Motor Type: 2-Phase Hybrid Stepper Motor

• Encoder Resolution (Closed Loop): 1000PPR

• Structure: L-Shaped Integrated Design

• Power Supply: DC 24V / 36V / 48V

Specifications

The Closed Loop Integrated Stepper Motors Driver series supports a wide range of performance configurations:

• Torque Range: 0.4N.m – 12N.m

• Frame Sizes: NEMA17 / NEMA23 / NEMA24 / NEMA34

• Rated Current Options: 2.5A / 4.0A / 6.0A

• High torque at low speed

• Stable output at high speed

• Reduced vibration and noise

Product Selling Points

• Closed Loop & Open Loop Options in one series

• Integrated Motor + Driver + Encoder design

• L-Shaped Compact Structure saves installation space

• Wide Torque Range up to 12N.m

• Multiple Voltage and Current Options

• Industrial-Grade Reliability

The Closed Loop Integrated Stepper Motors Driver is optimized for both cost efficiency and performance stability.

Product Features

• Real-time encoder feedback (closed loop)

• Automatic step loss correction

• Anti-resonance control algorithm

• High torque density

• Compact L-shaped mechanical design

• Built-in protection functions

Each Closed Loop Integrated Stepper Motors Driver is tested for long-term continuous operation.

Product Technology

The Lichuan Closed Loop Integrated Stepper Motors Driver utilizes advanced DSP digital control technology combined with encoder feedback.

The control algorithm dynamically adjusts phase current and torque output based on real-time position data, ensuring smooth motion and accurate positioning.

Product Working Principle

1. Control signals are sent to the Closed Loop Integrated Stepper Motors Driver

2. Driver converts signals into motor phase currents

3. Encoder (1000PPR) feeds back real-time position data

4. Control system compares target vs actual position

5. Motor motion is corrected instantly to avoid step loss

Application Fields

The Closed Loop Integrated Stepper Motors Driver is widely used in:

• Industrial automation systems

• CNC machines and engraving machines

• Laser cutting and marking equipment

• Packaging and labeling machinery

• Robotics and motion platforms

• Semiconductor and electronics equipment

Product Applications

Typical applications include:

• Multi-axis CNC motion control

• Linear guide and ball screw systems

• Automatic assembly lines

• Smart factory equipment

• Precision positioning modules

Product Parameter Table

Product Advantages

• Eliminates step loss in closed-loop mode

• Compact structure reduces cabinet space

• Easy installation and simplified wiring

• Wide compatibility with controllers

• Lower cost than servo systems

The Closed Loop Integrated Stepper Motors Driver is an ideal balance between performance and cost.

Product Services

We provide full support for Closed Loop Integrated Stepper Motors Driver, including:

• Technical consultation and selection guidance

• OEM / ODM customization

• Sample testing and evaluation

• Fast global logistics support

FAQ

Q1: What is the difference between closed loop and open loop versions?
A: The closed loop Integrated Stepper Motors Driver uses encoder feedback to prevent step loss and improve accuracy.

Q2: Can this product replace a servo motor?
A: In many medium-load applications, the Closed Loop Integrated Stepper Motors Driver is a cost-effective alternative.

Q3: What control signals are supported?
A: Pulse/Direction and communication-based control (model dependent).

Production Process

Each Closed Loop Integrated Stepper Motors Driver undergoes:

1. Precision motor manufacturing

2. Driver PCB assembly

3. Encoder calibration

4. Integrated system assembly

5. Aging and load testing

Operation Method

1. Connect power supply (24V / 36V / 48V)

2. Wire control signals and I/O

3. Configure parameters if required

4. Power on and test motion

5. Start normal operation

Precautions

• Do not exceed rated voltage and current

• Ensure proper grounding

• Avoid incorrect encoder wiring

• Maintain sufficient cooling space

Company Introduction

Lichuan is a professional manufacturer of Closed Loop Integrated Stepper Motors Driver and motion control products.
We focus on reliable, cost-effective solutions for global automation, CNC, and intelligent manufacturing industries.

Product Certificates

• CE Certification

• RoHS Compliance

• ISO Quality Management System

All Closed Loop Integrated Stepper Motors Driver products meet international standards.

Quality Assurance

• 100% functional testing before shipment

• Strict quality inspection procedures

• Stable long-term performance guarantee

Customer Service Information

• Professional technical support team

• Fast response within 24 hours

• After-sales service and technical guidance

• Long-term cooperation support for B2B customers
